SENIOR DUAL-CHAMBER ORIFICE FITTINGS
SENIOR DUAL-CHAMBER ORIFICE FITTINGS

Features :

  • Regularly scheduled maintenance is critical to ensuring the longevity, reliability and performance of your system. With this program, you can keep your control system hardware and software maintenance requirements current while establishing a flexible pa
  • Minimize measurement uncertainty with unique fourpoint positioning system that ensures concentricity
  • Achieve custody transfer accuracy without the need for expensive flow calibration
  • Operate safely with indicator plates that clearly show if the slide valve is in the open or closed position
  • Satisfy a variety of application requirements with a wide range of line sizes and ANSI ratings available
  • Eliminate damage and/or equipment failure with a design that provides an optimal seal
  • Use with a wide variety of Daniel Universal and Paddle Type Plates and Plate Seals
  • Expedite installation with no need for costly bypasses or additional valves; mount in vertical or horizontal plane

Specifications :

Measurement Type Differential pressure
Fluid Type Liquid, gas
Discharge Coefficient Uncertainty In accordance with AGA 3/API 14.3
Line Size 2-in to 24-in (50-mm to 609-mm)
Max. Operating Pressure ANSI 2500
Process Temperature Range -20 F to +160 F (-29º C to +71º C )
Flange Type ANSI Raised Face, ANSI RTJ
Process Wetted Material Carbon Steel (WCB and LCC), 316/316L SST, Duplex
Trim Options Standard Service, Sweet Service, Sour Service, Low Temperature
