- Maximum fluid working pressure: 120 psi (0.8 MPa, 8 bar)
- Air pressure operating range: 20-120 psi (0.14-0.8 MPa, 1.4-8 bar)
- Maximum air consumption: 125 scfm
- Maximum free-flow delivery: 100 gpm (378.5 l/min)
- Maximum pump speed: 200 cpm
- Maximum size pumpable solids: 5.8 in. (15.9 mm)
- Maximum fluid operating temperature is based on the following maximum diaphragm, ball, and seat temperature ratings:
PTFE balls; PTFE 2-piece diaphragm 220oF (104.4oC)
PTFE/EPDM overmolded (HD) diaphragm 180oF (82oC)
Santoprene balls or diaphragm 180oF (82.2oC)
EPDM 275oF (135oC)
3A Approved EPDM overmolded diaphragm 275oF (135oC)
- Air inlet size: 0.5 in. npt(f)
