- Maximum fluid working pressure: 410 psi (2.9 MPa, 28.7 bar)
- Maximum air inlet pressure: 80 psi (0.6 MPa, 5.5 bar)
- Maximum recommended pump speed: 60 cpm, 14 gpm (53 l/min)
- Maximum size pumpable solids: 1/4 in. (6.4 mm)
- Maximum operating temperature: 140oF (60oC)
- Maximum ambient temperature (air motor): 120oF (49oC)
- Air inlet: 1/2 in. npt(f)
- Air exhaust: 3/4 in. npt(m)
- Pump inlet type
4 in. (10.2 cm) Slotted
90 degree elbow, 2.5 in. (6.3 cm) Tri-clamp
4 in. (10.2 cm) Priming Piston
4 in. (10.2 cm) Priming Piston with flange for 6 in (15.2 cm) Clamp
4 in. (10.2 cm) Slotted with flange for 6 in. (15.2 cm) Clamp
- Fluid outlet: 2 in. Tri-clamp
