- Maximum fluid working pressure: 1450 psi (10.1 MPa, 100.4 bar)
- Maximum air inlet pressure: 100 psi (0.7 MPa, 6.9 bar)
- Maximum recommended pump speed: 60 cpm, 8.5 gpm (32 l/min)
- Maximum size pumpable solids: 1/4 in. (6.4 mm)
- Maximum operating temperature: 160oF (71oC)
- Maximum ambient temperature (air motor): 120oF (49oC)
- Air inlet: 1/2 in. npt(f)
- Air exhaust: 3/4 in. npt(m)
- Fluid inlet type: 4.1 in. (10.4 cm) tube with flange for 6 in. (15.2 cm) Tri-clamp
- Fluid outlet: 2 in. (5.1 cm) Tri-clamp
