- Maximum fluid working pressure: 100 psi (0.7 MPa, 7 bar)
- Air pressure operating range: 30-100 psi (0.21-0.7 MPa, 2.1-7 bar)
- Maximum air consumption: 28 scfm (0.672 m3/min)
- Maximum free-flow delivery: 16 gpm (61 l/min)
- Maximum size pumpable solids: 2.5 mm (0.09 in)
- Maximum pump speed: 400 cpm
- Maximum diaphragm operating temperature
PTFE: 220oF (104.4oC)
Santoprene 180oF (82.2oC)
Buna-N: 180oF (82.2oC)
TPE: 150oF (65.5oC)
- Air inlet size: 1/4 in. npt(f)
- Fluid inlet & outlet size: 3/4 in. npt(f) or bspt(f)
