Husky 1050 AODD

- Maximum fluid working pressure: 125 psi (0.86 MPa, 8.6 bar)

- Air pressure operating range: 20-125 psi (0.14-0.86 MPa, 1.4-8.6 bar)

- Air consumption at 4.8 bar, 76 lpm: 25 scfm

- Maximum free-flow delivery: 50 gpm (189 l/min)

- Maximum pump speed: 280 cpm

- Maximum size pumpable solids: 3.2 mm (1/8 in)

- Air inlet size: 1/2 in. npt(f)

- Fluid inlet & outlet size: 1 in raised face ANSI/DIN flange
