Features :
Specifications :
Line Size | DN50 to DN400 (2-in to 16-in) |
Fluid Type | Liquid |
Operating Temperature Range | -29º C to +66º C (-20º F to +150º F) |
Operating Pressure Range | ANSI 150 to 600 |
Materials of Construction | • Valve Body: Carbon Steel, ASTM A352 GR LCC • Valve Cylinder: DN50 to DN 200 (2-in to 4-in): Stainless Steel, ANSI 150 to 600; DN250 to DN 400 (6-in to 16-in) Carbon Steel, Nickel Coated, ANSI 150 to 600 • Valve Piston: Standard: Stainless Steel |
Materials of Construction | • Seat Ring: DN50 to DN200 (2-in to 6-in) Stainless Steel; DN300 to DN400 (8-in to 16-in) Carbon Steel, Nickel Coated • O-Rings: Standard: Viton; Optional: Neoprene, EPR, Viton, all Buna-N, Kalrez / Teflon AP (Aggressive Products) |
